SPECIFICATIONS EYE Plan eyepieces DIN wide field HWF 10x / 22 mm HEAD Head trinocular, inclined 45 °. Adjusting the interpupillary distance on the tube-holder left eyepiece • The interpupillary distance is adjustable from 54 to 75 mm • Output trinocular upright for photo/video and selector image 100:0% and 80-20%. REVOLVER HOLDER OBJECTIVES Revolver holder objectives quintuple oriented towards the interior. OBJECTIVES • Objectives long working distance (LWD) Plan Fluarex with correction to infinity. Magnification factors of 10x/0.30, 20x/0.45 and 40x/0.65. All the optics are coated with anti-fungal and anti-reflective to obtain the maximum performance of the light APPROACH Controls, macro focus and fine on-axis coaxial. Precision 2 μm, a total distance of approximately 24 mm. STAGE Plate 250x230mm with stage mechanical X-y 120 x 78 mm Is supplied with the following accessories: · Metal plate for Ø 35mm for the crop. · Plate for fastening of preparations of 76x26mm. · Glass plate. CAPACITOR A. N. 0.30 iris diaphragm. Working distance 72mm. ILLUMINATION FOR FLUORESCENCE It is supplied with 2 filters for fluorescence: · Blue: EX465-495 (BP) DM505 (LP) EM515-558 (BP) · Green: EX520-600 (BP), DM600 (LP) EM605-665 (BP) LIGHTING Transmitted 5W LED with adjustable intensity and internal transformer for 100-240V power. Fuse 3.15 A / 250V. PACKAGING Supplied with power cable, cover anti-dust and manual of instructions.
